RELATIVE PROPERTIES

SIRAPID 3351 Steel

Designation by Standards



Brand Name

Ravne

Mat. No.

DIN

EN

AISI/SAE

SIRAPID 3351

BRM4

1.3351

-

HS6-5-4

M4

Chemical Composition (in weight %)



C

Si

Mn

Cr

Mo

Ni

V

W

Others

1.33

max. 0.45

max. 0.40

4.15

4.60

-

3.95

5.60

-

Description

M4 Molybdenum High Speed Tool Steels. It has a relatively high 1.3% carbon content for high hardness and excellent wear resistance.



Applications

Used for cutting tools of all types for machining operations. Heavy duty milling cutters, broaches, broaches.



Physical properties (average values) at ambient temperature

Density [g/cm3]: 7.97

Transformation temperatures (oC): Ac1=803, Ac3=895



Coefficient of Linear Thermal Expansion 10-6 oC-1



20-100oC

20-200oC

20-300oC

20-400oC

20-500oC

20-600oC

20-700oC

20-800oC

9.4

10.4

10.9

11.3

11.5

11.8

12.0

12.1

Soft Annealing

Heat to 820-848oC, cool slowly in furnace. This will produce a maximum Brinell hardness of 255.



Hardening

Heat up to 450-600oC, 1st pre-heating: 850oC, 2nd pre-heating: 1050oC. Harden from a temperature of 1190-1230oC followed by oil, air quenching or warm bath quenching at 400oC.

Tempering

Tempering temperature: 540-560oC, 3x for 1 hour.



Tempering Temperature (oC) vs. Hardness (HRC)



200oC

300oC

400oC

500oC

525oC

550oC

575oC

600oC

650oC

700oC

63

62

62

64

64.5

65

64

62

57

47


Tempering Diagram


Forging

Hot forming temperature: 1100-900oC.



Cold Working

Cold working may be accomplished by conventional methods with the alloy in the annealed condition.



Machinability

Machinability is relatively low, rating 40% that of the water hardening (W group) tool steels which are relatively easy to machine.



Corrosion Resistance

Not normally employed in applications requiring corrosion resistance.



Welding

This is an alloy steel and may be welded. Consult the supplier for details. Forms manufactured: Please see the Dimensional Sales Program.
